CE and SGS Certified Pneumatic Actuator with Namur Mounting for Industrial Applications
Dettagli:
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 1 |
|---|
|
Informazioni dettagliate |
|||
| Modello n.: | VS-052 ~ VS-400 | Forma adeguata: | Tipo di commutazione |
|---|---|---|---|
| Tipo di lavoro: | Rotante | Pressione: | Pressione media |
| Temperatura di lavoro: | Temperatura normale | Tipo di recitazione: | Doppio recitazione |
| Materiale: | Alluminio | Struttura: | Rack e pignone |
| Attuatore rotativo: | Azionamento pneumatico | Materiale del pignone: | Acciaio legato indurito |
| Rivestimento del pignone: | Nichelato (oltre 15um) | Rivestimento del corpo dell'attuatore: | Anodizzato duro (oltre 30um) |
| Rivestimento del cappuccio terminale: | Rivestimento epossidico (oltre 80um) | Rivestimento del pistone: | Anodizzato duro (oltre 30um) |
| Regolazione del viaggio: | ±5º in entrambe le posizioni | ||
| Evidenziare: | CE Certified Pneumatic Actuator,SGS Certified Pneumatic Actuator,Namur Mounting Pneumatic Actuator |
||
Descrizione di prodotto
Pneumatic Actuator China Manufacturer
Position Indicator
A position indicator with Namur mounting is standard on all VESON pneumatic actuators for mounting accessories.
Precision Pinion
Hardened alloy steel pinion is precision ground and Nickel plated (over 15μm) to reduce friction and provide maximum wear resistance. Fully conforms with ISO5211 & DIN3337 standards. Custom dimensions available with stainless steel and aluminum alloy options.
Durable Actuator Body
Hard anodized aluminum extrusion (over 30μm) protects against wear and corrosion while minimizing piston friction. Optional Epoxy Coated and PTFE Coated treatments available.
Corrosion-Resistant End Cap
Epoxy coated (over 80μm) die casting aluminum end caps provide maximum resistance against corrosive elements. PTFE Coated treatments also available.
Precision Piston
Precisely balanced, hard anodized (over 30μm) die casting aluminum piston with high quality guides. Twin rack and pinion design ensures constant torque output.
Adjustable Travel
Standard adjustment of ±5° in both open and closed positions through easily accessible external adjustment bolts.
High Performance Springs
High tensile steel springs with epoxy coating for corrosion resistance and extended service life. Pre-loaded springs can be safely and rapidly disassembled.
Premium Bearings & Guides
Highly durable compound material provides high thrust stability with minimum friction for long operational life.
